Wizord 4i energizer Features:
Description Model PLC-425M-AU-IR3/PR Imaging Device 1/2.7″ Effective Pixels 5MP 2592(H)×1944(V) Scanning System Progressive CMOS Min. Illumination Color 0.05lux @ F1.2(AGC ON); B/W 0 lux @ IR ON Focal Length (Zoom Ratio) 3.6mm Max. Aperture Ratio F No. 1.6±5% Angular Field of View Horizontal:81°, Vertical:57°, Diagonal:108° Min. Object Distance 0.2M Lens Type Fixed(M12) IR Viewable Length Up to 30m Camera Title On/Off Day & Night IR cut filter with auto switch Day/Night/Auto/Schedule) Backlight Compensation Off/On (5 Zone) Wide Dynamic Range DWDR Digital Noise Reduction 3D DNR Motion Detection Off/On (8 Level) Privacy Masking Off/On (4 Zone, Rectangle) Gain Control Auto White Balance Auto/Manual/Indoor Electronic Shutter Speed 1/5 ~ 1/20000s Flip / Mirror Flip/Rotation Alarm NO Audio Built-in microphone Hardware Reset Yes Ethernet RJ45(10/100BASE-T) Video Compression Format H.265/H.264 Resolution Main Stream 5MP (2592*1944), 4MP (2592×1520),3MP (2304×1296), 1080P(1920×1080), 720P(1280×720), Sub Steam 720P(1280×720), VGA (640×480), QVGA (320×240) Mobile Stream QVGA(320×240) Max. Framerate 5MP ~ 20fps 4MP ~ 30fps Video Quality Adjustment 8Kbps ~ 8Mbps Bitrate control method CBR/VBR Streaming Capability Triple-Stream (Main/Sub/Moile) IP IPv4 Protocol TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP Security IP address filter; complicated password; Authenticated username and password Streaming Method Unicast/Multicast Max. User Access Max 7 (Admin User) Application Programming Interface ONVIF (Profile S/G/T) Web Viewer IE8,9,10,11, Chrome 44/lower, Firefox 51/lower, Operating Temperature / Humidity -30~ 60°C/less than ≤ 95% RH Ingress Protection IP67 Input Voltage / Current D12V/POE(IEEE802.3af) Power Consumption 12V/2A Color / Material White/Metal Weight 650g
